Spectrum Auctions for Beginners

This entry is part 3 of 6 in the series Africa and Spectrum 2.0

In the previous article, I looked at the merits of licensed vs. unlicensed spectrum and suggested that there might be scope for some new approaches. Here we’re going to deal with licensed spectrum and the process of auctioning spectrum which has become the dominant means of assigning popular licensed spectrum frequencies.

Spectrum auctions are now generally accepted as a “best practice” for assigning spectrum where demand exceeds availability. When spectrum was plentiful, administrative assignment seemed to work well enough but as demand for spectrum increased with the growth of wireless technologies, new methods were required. In the United States, the regulator experimented with spectrum lotteries where anyone could join a lottery for spectrum access. So called “beauty contests” where applicants for spectrum are qualitatively evaluation according to a set of criteria have also been used. It is easy to see the flaw in the randomness of a spectrum lottery but what’s wrong with a beauty contest? On the surface it seems eminently sensible to declare a set of policy goals and eligibility criteria and then evaluate applicants to find the most suitable. The reality is that the qualitative nature of these decisions tends to leave them open to challenge by disgruntled losers, especially if those losers are particularly well-resourced. Worse the decision-makers in a spectrum beauty contest become targets for influence.

auctionAnd this was exactly what economist Ronald Coase argued in 1959, that political pressures would inevitably result in misallocation of spectrum and administrative entities lack the decentralised information necessary to allocate spectrum effectively. Building on his own theory of economic efficiency he argued that if “property-like” rights were associated with spectrum licenses and transaction costs were low that the market could most efficiently organise the assignment of spectrum.

Coase argued that bid prices in auctions are a useful proxy for how organisations value spectrum with the assumption that those that value spectrum most would go on to create the highest social and economic value with that spectrum. Ignored for years, he was vindicated in 1994 when the U.S. regulator implemented the first spectrum auction. Since then spectrum auctions have gone on to become the dominant model for assigning high-demand spectrum.

Auction Goals

If the goal of a spectrum auction were simply maximising revenue, then auctions would not be nearly as complicated as the currently are. Regulators are often trying to achieve multiple goals through a spectrum auction, including:

  • ensuring efficient use of the spectrum band;
  • promoting a competitive telecommunications market and avoiding unbalanced concentration of ownership of spectrum;
  • avoiding manipulation of the auction; and,
  • generating public value in the form of revenue from the auction.

Achieving the right balance of all of the above turns out to be quite challenging. An auction is a game in which players strive to get as much spectrum as possible for as little money as possible. Auction participants often use the latest in game theory expertise and software modelling to optimise their outcome from a spectrum auction.

Because of the large amounts of money now involved (the 2008 700MHz auctions in the US generated nearly 20 billion dollars in revenue for the government) the rules of participation in a spectrum auction need to be crystal clear in order to both maximise trust in the process thereby encouraging participation and to avoid litigation as a result of an accusation of unfair play by a participant.

This means that auctions are now quite expensive to organise and run, sometimes costing in excess of a half million dollars. In fact, most auctions are now outsourced to spectrum auction consultants who assist in the design of the auction to achieve the government’s strategic goals as well as the execution of the auction.

It is safe to say that any regulator is well-advised to hire a spectrum auction consultant if only because they can be sure that the auction participants will be hiring auction experts as well.

Auction Types

There are two dominant types of spectrum auctions in use today.

Simultaneous Multi-Round Auction (SMRA)

This is the oldest and best known form of spectrum auction. In it, multiple lots of spectrum are auctioned simultaneously in a series of rounds. In this case a individual lot refers to a specific frequency band in a specific geographic area. An auction would typically have multiple frequency bands available in multiple regions. An SMRA auction is dependent on the regulator allocating the specific frequency lots prior to the auction so the bidders know exactly which chunk of spectrum in which geographic region they are bidding on.

Each round of bidding sets the standing high bid for each lot and the rounds continue until there is no excess demand. The great strength of this auction type is that it is comparatively simple and well-understood by all.  This facilitates speed in organising the auction as well as maximising the chance of participation.

Unfortunately the SMRA auction also has numerous drawbacks. The predetermined nature of the spectrum lots can lead to inefficiencies where some bidders may end up with non-contiguous blocks of spectrum. This may happen inadvertently or it may be a result of predatory bidding by competitors.

There is also the danger of prices going unnecessarily high with the winning bid paying significantly more than would have been required to win, the so-called “winner’s curse”.

Finally, there is the danger of tacit collusive behaviour on the part of bidders where an informal understanding among bidding entities may result in lower bid prices as each company targets a spectrum band that is understood to be theirs. Auctions designers have introduced rules into SMRA auctions that make this more difficult but it remains a risk.

Combinatorial Clock Auction (CCA)

The Combinatorial Clock Auction or CCA was designed to address many of the shortcomings of the SMRA auction. In a CCA auction, participants bid on generic lots of spectrum rather than individual lots. This means that the band plan for a given frequency at auction is not pre-determined as it is in an SMRA auction but is calculated after the auction in a manner designed to optimise the outcome for all successful bidders. This increases the likelihood of optimal use of the spectrum band as well as making it more difficult for participants to engage in collusive behaviour.

The auction then proceeds not by bids but by a “clock” process where in each bidding round a “clock” which represents the value of a generic lot of spectrum is incremented by a set amount. Bidders simply indicate whether they would be prepared to pay the price on the clock in that round. This is a subtle but important difference from the straightforward bid in the SMRA auction in that the clocks facilitate prices discovery among the participants. That is to say that the participant collectively inform each other through this process of how they value spectrum. Even with the best experts in the world, spectrum is a notoriously difficult thing to value and the price discovery function of a clock-style auction performs an essential function in normalising the value among the bidders.

Finally, instead of the winning bidder paying the full price of the winning bid, they pay the second highest price so it is still the case that whoever values the spectrum most wins but they pay no more than the minimum required to win. In a combinatorial auction with multiple lots and winners, this can get a bit complicated but the “2nd price rule” has evolved to cope with these complexities.

So, why doesn’t everyone just carry out CCA auctions now? Well, CCA has its weaknesses too. First, it is a much more complex auction to design and execute. This makes it a much more expensive undertaking and it also increases uncertainty on the part of participants who will not know exactly what spectrum they will get until the auction is over. That may be a disincentive to participation. CCA auctions work best with larger spectrum auctions often including multiple spectrum bands.

Spectrum Reserves in Auctions

A final contentious area of spectrum auction design is that of the reserve price or minimum opening bid for spectrum. Set the reserve too high and potential bidders may choose not to participate. Set it too low and run the risk of not realising the full value of the spectrum. There appears to be an unfortunate trend in spectrum auctions to place a disproportionate weight on the revenue generated from the auction as opposed to the revenue that will be generated by the cheaper and more pervasive access to telecommunications that occurs when spectrum is assigned efficiently and effectively. The economic impact of communication infrastructure is well-documented but seems to pale compared to the priority of maximising revenue from spectrum auctions. This seems like a mistake worth avoiding.

Activity Rules, Caps, Set-Asides

Spectrum auctions can be tweaked in different ways in order to prevent bad behaviour, encourage competition and/or limit the power of dominant players. For example, in order to last-minute bidding, activity rules can be established ensure that bidders must participate throughout the auction. Caps on spectrum ownership can be set to limit how much spectrum one player can own. Spectrum set-asides can be created to ensure spectrum is available to new players in the market. All of these tweaks are established to encourage specific outcomes and sometimes this works. It is also true however that the more complex a spectrum auction becomes, the greater the chance there is of an unexpected, undesirable outcome.

In Summary

As I read the news of spectrum auctions from around the world, I am reminded of what Winston Churchill said about democracy, that is was “the worst form of government, except for all those other forms that have been”. Perhaps that might be a good description of spectrum auctions, being the worst way to assign spectrum except for all the other ways that have been tried. Given the value that is now placed on spectrum, the risk involved in spectrum auctions for both the government and for bidders grows ever higher and as a result any failure to effectively and efficiently assign the spectrum grows ever more costly. I don’t expect spectrum auctions will go away any time soon but it does seem that we need a risk mitigation strategy to complement auctions of licensed spectrum that hopefully will reduce the impact of failure when it happens. Dynamic secondary use of spectrum such as “White Spaces” spectrum is likely one answer to this but as technology enables more nimbleness both at the wireless interface as well as at the management interface, new ideas and approaches are likely to continue to emerge.

How To Make The Digital Dividend Pay Out In Africa


Current television spectrum allocation

Digital Divide, Digital Dividend, Digital Yadi-yadah.  You would be forgiven if the term Digital Dividend didn’t immediately resonate with you given the proliferation of all things “Digital” in recent years.  A quick reminder then.  The Digital Dividend refers to the spectrum that is freed up in the conversion from analogue television broadcasting to digital broadcasting, also referred to as the Digital Switch-over (DSO), a change that has largely already taken place in the industrialised world and is slowly gathering pace in Africa.  This involves deploying digital transmitters to replace the analogue ones and either new digital televisions or digital Set Top Boxes (STBs) for existing televisions.  But the fact that more channels may become available or that you can receive television channels optionally in high-definition is less exciting to me than what can be done with the spectrum that is freed up. How much spectrum is being freed up?  There is over 400MHz of television spectrum.

Digital broadcasting uses a fraction of the spectrum that analogue broadcasting does and in Africa, there are few enough analogue terrestrial television channels per country to begin with.  What is more, it turns out that television spectrum exists within a very attractive range of the frequencies. What makes a frequency attractive?  Propagation or the ability of a radio wave to go through obstacles.  The lower down you go down the spectrum, the longer the radio waves and the less they are inclined to bounce off solid objects.   That means that you can cover a larger area with a single transmitter and that means that the cost of building a communication network drops significantly.  There are trade-offs however.  Longer waves carry less information so you can’t pack as much data into the same channel but that is a very reasonable trade-off when it comes to planning rural networks where the cost of network deployment may be a bigger issue than ensuring >20MB/s download speeds. So the Digital Dividend spectrum is extremely appealing from an infrastructure cost-of-ownership perspective.  It is unfortunate then that most of the debate around the Digital Dividend has largely been held within the broadcast community.  Not that digital broadcasting isn’t important but the Digital Dividend is an extremely valuable resource that needs to be considered holistically in terms of its national strategic value.

At the World Radio Congress (WRC-12) last year, there was confirmation of 790-862MHz (popularly known as the 800MHz band) as a global IMT (mobile) band. There was also a move by some African countries to have the 694-790MHz band (popularly known as the 700MHz band) made available in Region 1 (Africa and Europe) on an accelerated basis, probably because there are lots of CDMA players already in the 800MHz band. 700MHz is likely to be confirmed as an IMT band for Region 1 at the WRC in 2015.  So that’s good news for mobile operators except that the release of the 700MHz and 800MHz bands is being treated as contingent on the completion of the DSO.  Given the delays that have plagued the DSO on the continent, this seems like a dangerous strategy.  Why can’t one or both of these two new IMT bands be cleared for use while the DSO is going on in the lower end of the television spectrum?  At the very least, preparatory work for release of this spectrum ought to be going on now.


What a future allocation of spectrum might look like.

But the situation is worse than just a disconnect between the broadcaster and mobile operators.  There is also the prospect of missing out on an alternative access technology that could make a real difference for rural access.  Television White Spaces technology has the potential to create a vibrant rural access industry in Africa.

Television white spaces refers to the guard bands left between analogue television broadcast channels in order to prevent interference. TV White Spaces technology is capable of serendipitously re-using that empty spectrum without interfering with existing television broadcast. The initial vision was that through spectrum sensing, the devices would automatically use whatever empty spectrum was available, as a secondary user. That means if a television signal suddenly turn on in a frequency being used by a TV White Spaces device, it would automatically cease using that frequency and find another empty frequency to use. The broadcast and wireless microphone industry in the U.S. were not satisfied with this solution and the concept of an geo-located authentication database was introduced whereby TV White Spaces devices would need to authenticate against a spectrum database to see what spectrum was available for use in the area it was being used. Very low power TV White Spaces devices are still allowed to use just spectrum sensing. In general TV White Spaces regulation in the US has been the victim of massive lobbying and the result is some extremely hamstrung regulation.

The UK has largely followed the US regulation with one significant improvement. The power output level of the devices is not fixed but can be dictated by the settings in the authentication database. This means that higher power output levels could be assigned in sparsely populated rural areas versus areas where there are many other spectrum users.

What is exciting about this technology?

  1. No spectrum license required or at least a very nominal one. This means new opportunities for small entrepreneurs to provide alternative access.
  2. Great propagation. A typical TV White Spaces link can go 8-10km without any effort and is not obstructed by trees, buildings, etc.
  3. Innovation. WiFi has gone from a niche spectrum for experiments to an industry that is expected to be worth over 6 billion dollars in 2015. ~70% of smartphone data traffic in the rich world goes over WiFi. This is what open spectrum offers. TV White Spaces has the potential to be another such industry because of the low barrier to entry.
  4. No spectrum re-farming required. Because TV White Spaces technology is designed for secondary use of spectrum, there is no need to move the primary spectrum holder. This is a quick and easy win. Conflicts can be easily resolved by the regulator thanks to the authentication database.

TV White Spaces are finally gaining traction however.  Google is sponsoring a pilot in South Africa and in Kenya, Microsoft are supporting a pilot in partnership with the Kenyan government and a satellite operator there.  Those are good signs but in general the discussion of the Digital Dividend has been trapped in bureaucratic silos.  There needs to be a broader acknowledgement of the strategic value of the Digital Dividend and a strategy that addresses it holistically.
